Pyxis 5G LPWA Router

Built to meet utility-grade demands, Pyxis 5G LPWA delivers resilient LTE-M connectivity to the grid’s edge. Supporting SCADA, DER integration, and Distribution Automation, it seamlessly operates on existing pLTE networks or Ubiik’s freeRAN™ and goRAN™ pLTE systems. With broad frequency band compatibility across private and public LTE networks, Pyxis 5G LPWA is powered by a robust Qualcomm SoC, enabling advanced edge computing and fortified security. The ultimate choice for future-proof utility networks.

Ideal solution for connectivity to capacitor banks, reclosers, switches and a range of DA and DER grid assets.

higher security

edge computing capability

lower power consumption

The Maverick 220

module supports

B106

900

MHz

LTE-M

Network Architect

End Terminals

Pyxis 5G LPWA

public LTE

private LTE

Specifications

Standard

LTE-M

Platform

Dual-core ARM 64-bit A53 @ 1.0GHz Processor
8GB eMMC + 512MB DRAM

Frequency Band

B2, B4, B5, B12, B13, B20, B26, B66, B87, B88, B106

B111 (DL: 1820-1830 MHz, UL: 1800-1810 MHz)

ISM-FDD (DL: 925-928 MHz, UL: 902-915 MHz)

ISM-TDD (DL/UL 902-928 MHz)

B31
(DL: 462.5-467.5 MHz,
UL: 452.5-457.5 MHz)
B72 (DL: 461-466 MHz,
UL: 451-456 MHz)

Tx Power

23 dBm

26 dBm maximum

Modulation

QPSK, 16QAM

Power Supply

PoE IEEE 802.3 AF/AT
9-60 V (nominal 12V)

Antenna

Connections

1 x LTE-M
1 x GNSS

Indicators

2 x LED

Interfaces

2 x Ethernet -10/100 Base-T (RJ45 connectors)
2 x RS232/485 (RJ45 connectors)
1 x Console Port or 802.3 at PoE (RJ45)
GPIO (2 pins)
DC_In (2 pins)
1 x Nano SIM
1 x Reset Button

Physical and

environmental

Dimensions (LxWxH): 4.87" x 5.98" x 1.65" (123.7 x 151.9 x 41.91 mm)
Weight: 1.70 lbs (770g)
Operating Temperature: -4°F to +149°F (-20°C to +65°C )
Storage Temperature: -40°F to +185°F (-40°C to +85°C)
Humidity: 5% to 90% non-condensing
